SIREKN BEARING TOOLS SERIES


In order to ensure that the bearings have a longer life, SIRKEN has teamed up with China's outstanding grease gun manufacturers to provide customers with a variety of grease gun models. When faced with demanding grease needs, we recommend using SKF grease guns. We also provide customers with bearing heating tools and repair kits


SKF TMFT 36

TMFT 36 can be used for dismounting different bearings with bore diameters from 10 – 55 mm (0.39 – 2.17 in). The correct combination of compact ring and sleeve ensures effective transmission of mounting forces to the bearing ring via an interference fit, minimizing the risk of damage to the bearing raceways and rolling elements. TMFT 36 is also suitable for mounting other elements such as bushings, seals and pulleys.
Easy to achieve correct installation of bearings on shaft, housing and bore
The impact ring accurately contacts the inner and outer ring sides of the bearing.
The impact ring and impact sleeve are made of impact-resistant material, have a long service life and are suitable for use under pressure
The impact ring is clearly marked with size identification numbers for easy selection.
The anti-rebound hammer has nylon hammer heads on both ends to avoid damaging components.
All items come packaged in a sturdy, lightweight tool box with comprehensive guide and easy-to-follow bearing selection chart

Workpiece bore diameter10  –  55 mm
Workpiece outer diameter26  –  120 mm
Sleeve outer lengths
A, 228 mm
B, 235 mm
C, 245 mm
Sleeve, outer diameter
A, 25 mm
B, 45 mm
C, 66 mm
Hammer length315 mm
Hammer width115 mm


More models supported
