Bearing Name: 6326 M/C3
Bearing Type: Single row deep groove ball bearing
Bore diameter: 130 mm
Outside diameter: 280 mm
Width: 58 mm
Weight: 17.5 kg
Basic dynamic load rating: 229 kNBasic static load rating: 216 kN
Reference speed: 5000 r/min
Limiting speed: 4500 r/min
Bore type: Cylindrical
Cage: Machined metal
Radial internal clearance: C3
This 6326M C3 bearing is a Open Type Deep Groove Radial Ball Bearing with a Machined Brass cage.
