SIRKEN 24026BE-XL-S1 SPHERICAL ROLLER BEARING

Bearing Name:24026BE-XL-S1

Bore diameter：130mm

Outside diameter:200mm

Width:69mm

Basic dynamic load rating, radial:570,000 N
Basic static load rating, radial:860,000 N
Fatigue load limit, radial:103,000 N
Limiting speed:3,100 1/min
Reference speed:2,130 1/min
Weight:8.4 kg
Minimum diameter shaft shoulder:138.8 mm
Maximum diameter of housing shoulder:191.2 mm
Maximum recess radius:2 mm

The 24026BE-XL-S1 is a spherical roller bearing. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.
