SIRKEN-Tapered Roller Bearing 32226

Bearing Name: 32226

Taper Roller Bearings consist of the inner ring with the roller cage containing the tapered rollers known as the cone, and the separable outer ring referred to as the cup which allows the cone to be mounted separately. The bearing dimensions are 130x230x67.75mm.

Inside Diameter: 130mm
Outside Diameter: 230mm
Roller Bearing Type: Taper
Race Width :67.75mm
Bore Type :Parallel
Material :Steel
Static Load Rating: 830kN
Number of Rows: 1
Dynamic Load Rating :590kN
Limiting Speed :2800rpm
Reference Speed :2000rpm
Fatigue Limit Load :85kN

For more models please contact us

44649/10 67510 JM11949/10
H320/28 67512 JM12749/11
12649/10 67513 HM45449/10
H320/22  LM68149/10
HM48548 LM68149/11
69349/10 L44649R/10

15123/15245 104948/11 LM501349/10 LM29749/10

LM17887  LM300849/11 JM501349/10  29590/22 32008x1WC 104948/10  28680/22  LM501349/14

25580/25523 46790/20 47686/20 TR17887/31 25590/25520 528/520 M88043110 28584/21

786116 LM501349/11 28985/20 T2ED050 TR100802 29587/20

K497/K493 30305x2B 29586/20 594A/592 HM89249/10 803146/803110

K497/K492 HM89449/10 JM205149/10 HM212049/10

30306x2B 207049/10  655/653 TR070803  911244/10 HM88630/10 55206/55444 HM518445/10

T2ED100 29590/29522  29587/29520 307749/10  759/752 28985/20 3007910  9278/9220 TR070904 HM220149/10 JM822049/10

782/772 HM518445/10  HM220149/10 LM720249/10

M86649 T4DB170  JM46790/20 90381/90744 67048/67010

37941 738249/10   332/32  387/382A 320/22 88649/10 37431/625 320/28 89440/10 37425/625 320/32 89449/10 48548/10 390A 89446/10  37951      738249/10

104949/10 807813  104949/11  807713  11949/10 501349/501310  11749/10 29749/10  45449/10 12649

697920       17920

697716       17716

697724       17724 17722

697928       17814
