SIRKEN NNTR110x 260x115 ZZL S1 SUPPORT ROLLERS (YOKE-TYPE TRACK ROLLERS)

Support rollers (yoke-type track rollers) are designed to run on all types of tracks and to be used in cam drives, conveyor systems, etc. They are based on a double row full complement cylindrical roller bearing with an inner ring and have a thick-walled outer ring with a crowned running surface. They are supplied sealed and ready-to-mount. The inner ring contains lubrication holes to facilitate relubrication.

Bearing Name: NNTR110x 260x115 ZZL S1
Functional outside diameter:260 mm
Bore diameter:110 mm
Width, total:115 mm
Width, outer ring:113 mm
Basic dynamic load rating:627 kN
Basic static load rating:930 kN
Limiting speed:360 r/min
Weight:35.6 kg
