SIRKEN CF4BUU -Standard Type Cam Followers

(Caged Type)

CATEGORY:Cam Followers

Roller Type：Cylindrical Outer Ring

WEIGHT:0.0100 KGS

WIDTH (MM):12MM

LENGTH (MM):20MM

THREAD SIZE:M4 X 0.7

HEAD HEIGHT (MM):8MM

DYNAMIC LOAD RATING (KN):2.07

STATIC LOAD RATING (KN):1.59

Cam Followers are bearings with a stud incorporating needle rollers in a thick walled outer ring.These bearings are designed for outer ring rotation,and have superior rotational performance with asmall coefficient of friction.Also, they are designed to have minimal radial internal clearance to increase the loading zone, and thusreduce the effect of shock loads and ensure stablelong life.

·As studs already have threads or steps, they are easy to mount.

·With Cage

·Sealed Type

·With Hexagon Hole

·CFBUU Series
