SIKRNE PWTR50110-2RS-XL YOKE TYPE TRACK TOLLER

Item Number:PWTR50110-2RS-XL

Category:Support Roller

Inner (d) MM:50

Outer (D) MM:110

Width (B) MM;30

Weight (kg):1.69

Seal:2RS - Rubber Seal on Two Sides

Running Surface:Standard

Width inner ring (B) :32 mm

Basic dynamic load rating, radial (C r w):60000

Basic static load rating, radial (C 0r):92000

Speed on permanent grease lubrication (n D G)：1100

The PWTR50110-2RS-XL is a track roller or support roller with cylindrical rollers. These rolling elements combine a high load capacity with reasonable shock resistance. Track rollers are designed for use with various types of tracks. Thanks to a thick-walled outer ring, they can withstand high radial loads. Axial loads can be absorbed in both directions due to alignment errors or misalignment. Yoke-type track rollers are suitable for mounting on a shaft. They are not mounted in a housing bore, but a flat (counter) track provides support.

The PWTR50110-2RS-XL has a full complement design. The absence of a cage allows for a greater number of rolling elements, making this track roller highly loadable. Full complement track rollers are also more shock-resistant than track rollers with cages. However, the maximum rotational speed is lower than that of caged variants. Common applications of track rollers include conveyor systems, linear guidance systems, and cam mechanisms.
